Popis
These sensors are available in 2 different mounting styles for flat or curved surfaces. The integral thermocouple sensor is bonded onto the inner surface of the self adhesive aluminum foil strip, which is provided for faster response times.
Comes with bare stripped ends as standard. You can order the probe, including the installation of connectors. Put the required connectors in the basket together with the probe. If needed, order the required connectors separately, see „Related Products“ below.
SPECIFICATIONS:
Dimensions: SA2C: 15 x 50 x 6.4 mm; SA2F: 35 x 12 x 6.4 mm
Wire: 24 AWG stranded thermocouple wire, 1 m (40″) and 2 m (80″) lengths; custom lengths available
Complete informations can be found in the spec sheet (PDF), see the „Download“ section.
